GM Vehicles shown throughout with third-party equipment and alterations installed by an independent supplier/upfitter.
IMPORTANT NOTE ABOUT ALTERATIONS AND WARRANTIES: Installations or alterations to the original-equipment vehicle or chassis distributed by General Motors are not covered by the General Motors New Vehicle Limited Warranty. The independent special body company, assembler, equipment installer, or upfitter is solely responsible for warranties for any alterations (or any effect of the alterations) to any of the parts, components, systems, or assemblies manufactured by GM. GM is not responsible for the safety or quality of design, features, materials, or workmanship of any alterations by such independent suppliers.

UPFIT APPLICATIONS

CARGO BODY

GM Envolve offers a wide variety of vehicles to haul your cargo and help protect it from the elements. Our vehicles have maximum versatility and can be upfitted for your business needs.

COMPATIBLE MODELS

Chevrolet Express 3500 Cutaway/GMC Savana 3500 Cutaway

Chevrolet Express 4500/GMC Savana 4500 Cutaway

Chevrolet Silverado 1500/GMC Sierra 1500

Chevrolet Silverado 2500 HD/GMC Sierra 2500 HD

Chevrolet Silverado 3500 HD/GMC Sierra 3500 HD

Chevrolet Silverado 3500 HD Chassis Cab/GMC Sierra 3500 HD Chassis Cab

CARGO BODY VAN UPFIT OPTIONS

GM´s fleet-tailored Cargo Body Van packages help make it easy to haul any payload with a multiple engine options and Gross Vehicle Weight Ratings.

APPLICATION CHARTS

CHEVROLET EXPRESS 3500 CUTAWAY/GMC SAVANA 3500 CUTAWAY

CUTAWAY

2WD SRW

WB/Cab to Axle

3,531 mm (139 in.)/2,032 mm (80 in.)

Cab to end of frame

3,771 mm (148.45 in.)

Front Maximum GAWR

1,860 kg (4,100 lb.)

Maximum GVWR

4,491 kg. (9,900 lb.)

Maximum Payload

2,431 kg (5,360 lb.)

2WD SRW

WB/Cab to Axle
4,039 mm (159 in.)/2,540 mm (100 in.)

Cab to end of frame
4,279 mm (168.45 in.)

Front Maximum GAWR

1,860 kg (4,100 lb.)

Maximum GVWR

4,491 kg (9,900 lb.)

Maximum Payload

2,300 kg (5,070 lb.)

2WD DRW

WB/Cab to Axle

4,496 mm (177 in.) / 2,997 mm (118 in.)

Cab to end of frame

4,736 mm (186.45 in.)

Front Maximum GAWR

1,950 kg. (4,300 lb.)

Maximum GVWR

5,579 kg (12,300 lb.)

Maximum Payload

3,211 kg (7,080 lb.)

CHEVROLET EXPRESS 4500 CUTAWAY/GMC SAVANA 4500 CUTAWAY

CUTAWAY

2WD DRW

WB/Cab to Axle

4,039 mm (159 in.)/2,540 mm (100 in.)

Cab to end of frame

4,279 mm (168.45 in.)

Front Maximum GAWR

2,087 kg (4,600 lb.)

Maximum GVWR

6,441 kg (14,200 lb.)

Maximum Payload

4,046 kg (8,920 lb.)

2WD DRW

WB/Cab to Axle

4,496 mm (177 in.) / 2,997 mm (118 in.)

Cab to end of frame

4,736 mm (186.45 in.)

Front Maximum GAWR

2,087 kg (4,600 lb.)

Maximum GVWR

6,441 kg (14,200 lbs.)

Maximum Payload

4,023 kg (8,870 lb.)

CARGO BODY TRUCK UPFIT OPTIONS

GM Envolve gives you the power and reliability of Chevrolet and GMC trucks. Our wide selection of trucks includes both gas and diesel engines and a variety of Gross Vehicle Weight Ratings.

APPLICATION CHARTS

CHEVROLET SILVERADO 1500/GMC SIERRA 1500 AVAILABLE W/BOX DELETE

REGULAR CAB

2WD/4WD SRW

WB/Cab to Axle

3,545 mm (140 in.) /1,403 mm (55.2 in.)

Body Length

8 ft.

Front Maximum GAWR

1,724 kg (3,800 lb.)

Maximum GVWR

3,130 kg (6,900 lb.)

Maximum Payload

1,148 kg (2,530 lb.)

CHEVROLET SILVERADO 2500 HD/GMC SIERRA 2500 HD AVAILABLE W/BOX DELETE

REGULAR CAB

2WD/4WD SRW

WB/Cab to Axle

3,596 mm (142 in.) / 1,403 mm (55.24 in.)

Body Length

8 ft.

Front Maximum GAWR

2,359 kg (5,200 lb.)

Maximum GVWR

5,001 kg (11,025 lb.)

Maximum Payload

1,851 kg (4,081 lb.)

DOUBLE CAB

2WD/4WD SRW

WB/Cab to Axle

4,127 mm (162 in.) /1,403 mm (55.24 in.)

Body Length

8 ft.

Front Maximum GAWR

2,540 kg (5,600 lb.)



Maximum GVWR

5,194 kg (11,450 lb.)

Maximum Payload

1,781 kg (3,926 lb.)

CREW CAB

2WD/4WD SRW

WB/Cab to Axle

4,369 mm (172 in.)/1,403 mm (55.24 in.)

Body Length

8 ft.

Front Maximum GAWR

2,540 kg (5,600 lb.)

Maximum GVWR

5,239 kg (11,550 lb.)

Maximum Payload

1,786 kg (3,937 lb.)

CHEVROLET SILVERADO 3500 HD/GMC SIERRA 3500 HD AVAILABLE W/BOX DELETE

REGULAR CAB

2WD/4WD SRW

WB/Cab to Axle

3,596 mm (142 in.) / 1,403 mm (55.24 in.)

Body Length

8 ft.

Front Maximum GAWR

2,359 kg (5,200 lb.)

Maximum GVWR

5,352 kg (11,800 lb.)

Maximum Payload

2,082 kg (4,590 lb.)

DOUBLE CAB

2WD/4WD SRW

WB/Cab to Axle

4,127 mm (162 in.) /1,403 mm (55.24 in.)

Body Length

8 ft.

Front Maximum GAWR

2,540 kg (5,600 lb.)

Maximum GVWR

5,511 kg (12,150 lb.)

Maximum Payload

2,025 kg (4,464 lb.)

CREW CAB

2WD/4WD SRW

WB/Cab to Axle

4,369 mm (172 in.)/1,403 mm (55.24 in.)

Body Length

8 ft.

Front Maximum GAWR

2,540 kg (5,600 lb.)

Maximum GVWR

5,557 kg (12,250 lb.)

Maximum Payload

2,028 kg (4,472 lb.)

CHEVROLET SILVERADO 3500 HD/GMC SIERRA 3500 HD CHASSIS CAB

REGULAR CAB

2WD/4WD DRW

WB/Cab to Axle

3,716 mm(146 in.)/1,524 mm (60 in.)

Body Length

8 ft., 9 ft.

Front Maximum GAWR

2,359 kg (5,200 lb.)

Maximum GVWR

6,350 kg (14,000 lb.)

Maximum Payload

3,314 kg (7,306 lb.)

2WD/4WD DRW

WB/Cab to Axle

4,339 mm (171 in.) /2,134 mm (84 in.)

Body Length

10 ft., 11 ft.

Front Maximum GAWR

2,540 kg (5,600 lb.)

Maximum GVWR

6,350 kg (14,000 lb.)

Maximum Payload

3,260 kg (7,188 lb.)

CREW CAB

2WD/4WD DRW

WB/Cab to Axle

4,490 mm (177 in.)/  1,524 mm (60 in.)

Body Length

8 ft., 9 ft.

Front Maximum GAWR

2,540 kg (5,600 lb.)

Maximum GVWR

6,350 kg (14,000 lb.)

Maximum Payload

3,074 kg (6,777 lb.)

NEXT STEPS

Business Elite Dealers are experienced with  commercial needs and can help you make the best fleet purchase tailored for your business.

Here you can find technical information for upfits including the latest specifications, guidelines and best practices.

Get an experienced upfitter with a proven track record of working with General Motors parts and vehicles.
