GM Envolve offers trucks that give you a versatile platform to help create whatever your business needs. No matter what you need to transport, tow or upfit†, one of our many options can help you get the job done.
COMPATIBLE MODELS
Chevrolet Silverado 1500/GMC Sierra 1500
Chevrolet Silverado 2500 HD/GMC Sierra 2500 HD
Chevrolet Silverado 3500 HD/GMC Sierra 3500 HD
Chevrolet Silverado 3500 HD Chassis Cab/GMC Sierra 3500 HD Chassis Cab
PLATFORM/STAKE BODY UPFIT OPTIONS
GM Envolve trucks offer 2WD or 4WD options, as well as Gross Vehicle Weight Ratings† of up to 6,350 kg (14,000 lb.). to help make sure your needs are met.
APPLICATION CHARTS
CHEVROLET SILVERADO 1500/GMC SIERRA 1500 AVAILABLE W/BOX DELETE
REGULAR CAB
2WD/4WD SRW
WB/Cab to Axle
3,545 mm (140 in.) / 1,403 mm (55.2 in.)
Body Length
8 ft.
Front Maximum GAWR†
1,724 kg (3,800 lb.)
Maximum GVWR†
3,130 kg (6,900 lb.)
Maximum Payload†
1,148 kg (2,530 lb.)
CHEVROLET SILVERADO 2500 HD/GMC SIERRA 2500 HD AVAILABLE W/BOX DELETE
REGULAR CAB
2WD/4WD SRW
WB/Cab to Axle
3,596 mm (142 in.) / 1,403 mm (55.24 in.)
Body Length
8 ft.
Front Maximum GAWR†
2,359 kg (5,200 lb.)
Maximum GVWR†
5,001 kg (11,025 lb.)
Maximum Payload†
1,851 kg (4,081 lb.)
DOUBLE CAB
2WD/4WD SRW
WB/Cab to Axle
4,127 mm (162 in.)/1,403 mm (55.24 in.)
Body Length
8 ft.
Front Maximum GAWR†
2,540 kg (5,600 lb.)
Maximum GVWR†
5,194 kg (11,450 lb.)
Maximum Payload†
1,781 kg (3,926 lb.)
CREW CAB
2WD/4WD SRW
WB/Cab to Axle
4,369 mm (172 in.)/1,403 mm (55.24 in.)
Body Length
8 ft.
Front Maximum GAWR†
2,540 kg (5,600 lb.)
Maximum GVWR†
5,239 kg (11,550 lb.)
Maximum Payload†
1,786 kg (3,937 lb.)
CHEVROLET SILVERADO 3500 HD/GMC SIERRA 3500 HD AVAILABLE W/BOX DELETE
REGULAR CAB
2WD/4WD SRW
WB/Cab to Axle
3,596 mm (142 in.) / 1,403 mm (55.24 in.)
Body Length
8 ft.
Front Maximum GAWR†
2,359 kg (5,200 lb.)
Maximum GVWR†
5,352 kg (11,800 lb.)
Maximum Payload†
2,082 kg (4,590 lb.)
DOUBLE CAB
2WD/4WD SRW
WB/Cab to Axle
4,127 mm (162 in.)/1,403 mm (55.24 in.)
Body Length
8 ft.
Front Maximum GAWR†
2,540 kg (5,600 lb.)
Maximum GVWR†
5,511 kg (12,150 lb.)
Maximum Payload†
2,025 kg (4,464 lb.)
CREW CAB
2WD/4WD SRW
WB/Cab to Axle
4,369 mm (172 in.)/1,403 mm (55.24 in.)
Body Length
8 ft.
Front Maximum GAWR†
2,540 kg (5,600 lb.)
Maximum GVWR†
5,557 kg (12,250 lb.)
Maximum Payload†
2,028 kg (4,472 lb.)
CHEVROLET SILVERADO 3500 HD/GMC SIERRA 3500 HD CHASSIS CAB
REGULAR CAB
2WD/4WD DRW
WB/Cab to Axle
3,716 mm(146 in.)/1,524 mm (60 in.)
Body Length
8 ft., 9 ft.
Front Maximum GAWR†
2,359 kg (5,200 lb.)
Maximum GVWR†
6,350 kg (14,000 lb.)
Maximum Payload†
3,314 kg (7,306 lb.)
2WD/4WD DRW
WB/Cab to Axle
4,339 mm (171 in.)/2,134 mm (84 in.)
Body Length
10 ft., 11 ft.
Front Maximum GAWR†
2,540 kg (5,600 lb.)
Maximum GVWR†
6,350 kg (14,000 lb.)
Maximum Payload†
3,260 kg (7,188 lb.)
CREW CAB
2WD/4WD DRW
WB/Cab to Axle
4,490 mm (177 in.) / 1,524 mm (60 in.)
Body Length
8 ft., 9 ft.
Front Maximum GAWR†
2,540 kg (5,600 lb.)
Maximum GVWR†
6,350 kg (14,000 lb.)
Maximum Payload†
3,074 kg (6,777 lb.)
NEXT STEPS
Business Elite Dealers are experienced with commercial needs and can help you make the best fleet purchase tailored for your business.
Vehicles shown throughout with equipment from an independent supplier and are not covered by the GM New Vehicle Warranty. GM is not responsible for the safety or quality of independent supplier alterations.
GM Vehicles shown throughout with third-party equipment and alterations installed by an independent supplier/upfitter.
IMPORTANT NOTE ABOUT ALTERATIONS AND WARRANTIES: Installations or alterations to the original-equipment vehicle or chassis distributed by General Motors are not covered by the General Motors New Vehicle Limited Warranty. The independent special body company, assembler, equipment installer, or upfitter is solely responsible for warranties for any alterations (or any effect of the alterations) to any of the parts, components, systems, or assemblies manufactured by GM. GM is not responsible for the safety or quality of design, features, materials, or workmanship of any alterations by such independent suppliers.
